Yamaha Outboard Power Tilt and Trim Motors
Model/HP/Cyl |
Year |
Replaces |
Wire |
Arco Tilt Motor |
Sierra Tilt Motor |
| F30, F40 | 2001 & UP | 67C-43880-00-00, 67C-43880-01-00 | 2 | - | 18-6748 |
| 40 | 1994 | 6H1-43880-02 | 2 | 6260 | 18-6781 |
| 40-100 | 1995-2003 | 62X-43880-00-00, 62X-43880-01-00, 62X-43880-09-00 | 2 | 6266 | 18-6812 |
| 40 & C40 | 2003 & UP | 62Y-43800-11-00, 62Y-43880-00-00, 69W-43880-00-00 | 2 | 6259 | 18-6811 |
| 40-50 | 1985-1992 | 6H5-43880-02-00 | 2 | 6264 | 18-6788 |
| 50 | 1992-1995 | 6H1-43880-02 | 2 | 6260 | 18-6781 |
| 50 | 2003 & UP | 62Y-43800-11-00, 62Y-43880-00-00, 69W-43880-00-00 | 2 | 6259 | 18-6811 |
| F50 & T50 | 2003-2004 | 62Y-43800-11-00, 62Y-43880-00-00, 69W-43880-00-00 | 2 | 6259 | 18-6811 |
| 50-200 | 1985-1986 | 688-43880-11-00, 6E5-43880-01-00, 6E5-43880-02-00 | 3 | 6267 | 18-6821 |
| F50 & F60 | 2005-2006 | 6C5-43880-00-00, 6C5-43880-01-00 | 2 | 6257 | 18-6836 |
| P60 | 1991 | 6H1-43880-00-00 | 3 | 6267 | 18-6259 |
| 60 | 1997 & UP | 6H1-43880-02 | 2 | 6260 | 18-6781 |
| 60 HP 4 STROKE | 2002-2004 | 62Y-43800-11-00, 62Y-43880-00-00, 69W-43880-00-00 | 2 | 6259 | 18-6811 |
| 70 | 1984-1991 | 6E5-43880-01, 6E5-43880-02, 6H1-43880-00 | 3 | 6267 | 18-6259 |
| 70 | 1996 & UP | 6H1-43880-02 | 2 | 6260 | 18-6781 |
| F75 HP 4 STROKE | 2003-2004 | 67F-43880-00-00 | 2 | 6261 | 18-6787 |
| C80 | 1997 | 6H1-43880-02 | 2 | 6260 | 18-6781 |
| F80 HP 4 STROKE | 1999-2003 | 67F-43880-00-00 | 2 | 6261 | 18-6787 |
| C85 | 1991 | 6H1-43880-00 | 3 | 6267 | 18-6259 |
| 90 | 1987 | 6E5-43880-01, 6E5-43880-02, 6H1-43880-00 | 3 | 6267 | 18-6259 |
| 90 | 1992 & UP | 6H1-43880-02 | 2 | 6260 | 18-6781 |
| F90 HP 4 STROKE | 2003-2004 | 67F-43880-00-00 | 2 | 6261 | 18-6787 |
| F100 HP 4 STROKE | 1999-2002 | 67F-43880-00-00 | 2 | 6261 | 18-6787 |
| 115-200 (3-BOLT MOUNT) | 1987-1996 | 6G5-43880-00, 6G5-43880-01, 6G5-43880-02 | 2 | 6265 | 18-6760 |
| 115-225 (4-BOLT MOUNT) | 1997-2002 | 64E-43880-00, 64E-43880-01 | 2 | 6240 | 18-6783 |
| 130 | 1988-1996 | 6G5-43880-01, 6G5-43880-02 | 2 | 6265 | 18-6760 |
| 150 | 1984-1986 | 6E5-43880-01, 6E5-43880-02, 6H1-43880-00 | 3 | 6267 | - |
| 150 | 1987-1995 | 6G5-43880-01, 6G5-43880-02 | 2 | 6265 | 18-6760 |
| 175 | 1984-1986 | 6E5-43880-01, 6E5-43880-02, 6H1-43880-00 | 3 | 6267 | - |
| 175 | 1987-1995 | 6G5-43880-01, 6G5-43880-02 | 2 | 6265 | 18-6760 |
| 200 | 1984-1986 | 6E5-43880-01, 6E5-43880-02, 6H1-43880-00 | 3 | 6267 | - |
| 200 | 1987-1996 | 6G5-43880-01, 6G5-43880-02 | 2 | 6265 | 18-6760 |
| P200 | 1990-1993 | 6G5-43880-01, 6G5-43880-02 | 2 | 6265 | 18-6760 |
| F200, LF200, LZ200 | 2004-2006 | 69J-43880-00-00, 60V-43880-00-00 | 2 | 6263 | 18-6798 |
| 225 | 1990-1993 | 6G5-43880-01, 6G5-43880-02 | 2 | 6265 | 18-6760 |
| F225, LF225, LZ225 | 2004-2006 | 69J-43880-00-00, 60V-43880-00-00 | 2 | 6263 | 18-6798 |
| 225-250 (3 BOLT MOUNT) | 1990-1996 | 61A-43880-01-00, 61A-43880-02-00 | 4 | - | - |
| 225 V6 2.6L | 1994 | 6G5-43880-01, 6G5-43880-02 | 2 | 6265 | 18-6760 |
| F250 | 2005-2006 | 69J-43880-00-00, 60V-43880-00-00 | 2 | 6263 | 18-6798 |
| LF250, LZ250 | 2004-2006 | 69J-43880-00-00, 60V-43880-00-00 | 2 | 6263 | 18-6798 |
Model/HP/Cyl |
Year |
Replaces |
Wire |
Arco Tilt Motor |
Sierra Tilt Motor |
View Large Size
Yamaha 6G5-43880-02-00 replacement parts
Average Customer Review for Johnson, Evinrude Replacement Power Tilt and Trim Motor 6241 - Arco
Average Customer Review for PT609NK-3 2V 2-Wire Power Tilt & Trim Motor/Wire Harness for Yamaha Outboards - API Marine
Q:
Will this replace a yamaha f150 2006 model?
A:
No this is not for your year. We do have an OEM version if interested: http://www.iboats.com/Starting-Motor-Assy/dm/view_id.1310100
